EMITE I-Series RC

WLAN, 2G, 3G, 4G, W-IoT, MTC and Short-range small device testing









I50 - Small-size Reverberation Chamber
Internet of Things (IoT), Machine-Type-Communications (MTC), short-range communications and WLAN testing
690MHz to 6GHz



I 50 1







The I50 small-size Reverberation Chamber is an amber gem set of Over-the-Air (OTA) test chambers. With smart-stirring, the I50 chamber has the smallest footprint in the market and is intended for OTA testing of W-IoT (LTE-M, NB-IoT and EC-GSM-IoT), MTC (LoRa, Sigfox), short-range radio (BT 1.0/2.0, BLE, ZigBee, Z-Wave) and WLAN 802.11abgnac (2.4 and 5 GHz bands) technologies for small devices up to 15cm and 5kg.





Download Datasheet



dut   mcl


The I-Series chambers provide for fast and accurate TRP, TIS, downlink and uplink Maximum Coupling Loss (MCL) and Downlink and Uplink TCP/UDP MIMO TPUT tests for UEs, IoT modules, wearable devices, wireless stations (STAs) and Access Points (APs), also with user-selectable technology, band, channel (including DFS ones), bandwidth, antennas, rates (MCS) and other parameters in an individual manner for each test on a batch, which can then be run overnight in an unsupervised manner. LTE-M and NB-IoT TRP and TIS testing for different data Rates (@123kbps at the figure) provide a very good insight on IoT device performance on the field.

Maximum Coupling Loss (MCL) evaluated for a W-IoT NB-IoT d evice, showing the normal, extended and out of coverage regions.






Unique advantages of I-Series



night
Overnight campaign testing without human intervention
Signaling | WLAN (2.4 and 5GHz) | 2G-3G-4G | Batch testing| Customized Settings


wiot circle final
Small device testing
Up to 15cm DUTs | 1.0 dB STD | Wereables | W-IoT (LTE-M,NB-IoT) |  MTC (LoRA, Sigfox) |  Short-range (BT, BLE, ZigBee, Z-Wave) |  Up to 5kg DUTs
movl apps
Pre-calibrated Chamber and OS apps
VNA and No-VNA calibrations | UE Apps in iOS, macX, Android, Linux, UWP, Windows and Tizen









All in One Single and

Intuitive Graphic User

Interface


The I50 Reverberation Chamber provides unique WLAN, 2G-4G, W-IoT, MTC and Short Range signaling Figures of Merit, all united in one single and intuitive graphic user interface (GUI), allowing batch test cases be tested overnight in an unsupervised manner. Pass/Fail criteria can be set, providing excellent quality control of tested devices in a simplified manner.
gui ISeries

For additional information or a personalized quotation, please contact EMITE at This email address is being protected from spambots. You need JavaScript enabled to view it..

This email address is being protected from spambots. You need JavaScript enabled to view it.



Choose EMITE. Your MIMO wishes anticipated.
